ID PART NO. Item NO. Name Chinese Name Image Description QTY(pcs/set)
1 50CC-Engine-L-001 139.12.302 GASKET,LEFT CRANKCASE 侧盖纸垫 1
2 50CC-Engine-L-002 139.11.511 DOWEL PIN 8×6.5×14 定位销(8×6.5×14) 2
3 50CC-Engine-L-003 139.03.311C L CRANKCASE COVER 侧盖(小王子、五羊、悍马、短箱体) 1
4 50CC-Engine-L-004 40.05.401 Rubber sets 橡胶套 /
5 50CC-Engine-L-005 GB/T 16674.1 BOLT M6×35 螺栓 M6×35 8
6 50CC-Engine-L-006 40.07.600 SPEED FLIP-FLOP 限速触发器 /
7 50CC-Engine-L-007 GB/T 823 CROSS PAN HEAD SCREWS NAILS M5×8 十字槽盘头镙钉M5×8 /
8 50CC-Engine-L-008 40.11.307 SPEED TRIGGER PRESSURE CLAMP 1 限速触发器压线夹1 /
9 50CC-Engine-L-009 139.11.504 Brake clamp 刹车线夹 1
10 50CC-Engine-L-010 139.11.505 clamp I 线夹I 1
11 50CC-Engine-L-011 INTO THE AIR DUCT ASSEMBLY 短吸风管 1
