SPARTAN8(PAH125-8E)
SPARTAN8(PAH125-8E)
125cc, Air Cooled, Automatic with Reverse, 8 inches Wheel, Front Drum, Rear Disc Brake.
MSRP

N/A

Product Details

Engine 125cc, 157FMI, Kangdi
Transmission Fully automatic with Reverse
Drive type Chain
Belt and or chain size Chain: 420H 100L
Starter System Elec start
Fuel system Gasoline, 0.53gal, carburator
Brake (Front/Rear) Drum/Disk
Tire size(Front/Rear) 19x7-8 ; 18x 9.5-8
Wheel size and type(Front/Rear) 8, Steel
Oil capacity and type (in liters) 0.8L, Air cooled motorcycle oil with clutch additive
Gear oil type and capacity( in liters) N/A
Battery 12V/5Ah
Light Headlight is Led, taillight is standard, no turn lights
Suspension(Front/Rear) Double a-arm suspension / Single arm suspension
Dimensions(in inch) Assembled(LxWxH): 59.8x37x36.2, Crated(LxWxH): 51.6x31.1x26.8, Seat height: 26-3/8", Wheelbase: 37.8
Weight(net/gross/capacity) 266/321 lbs
weight capacity 198 lbs
Ground Clearance (in inch) 3.5
Assembly Require Wheels handlebars, front rear racks, battery
Any special features Remote kill key fob, throttle limiter
EPA/carb approved Yes/No
